UR 8FV GE UR8FV Multilin UR Relay Module

Power Supply:

• Voltage: 85-265 VAC / 100-300 VDC
• Frequency: 50/60 Hz

Input Ratings:

• Current Inputs: 1A or 5A
• Voltage Inputs: 100V or 120V

Relay Output:

• Contact Ratings: 10A at 250VAC
• Number of Outputs: Up to 8 programmable outputs

Measurement Accuracy:

• Current: ±1% of reading
• Voltage: ±0.5% of reading

Communication Ports:

• Ethernet: 10/100 Mbps
• Serial Ports: RS-232, RS-485

Dimensions:

• Size: 6”L, 7”W, 1.5”H
• Weight: 0.907 kg

Operating Temperature:

• -20°C to +60°C (-4°F to +140°F)
