TSX3721001 Schneider - Modular base controller
TSX3721001 Schneider - Modular base controller
Technical Specifications:
Manufacturer:
Schneider
Product No.:
TSX3721001
Condition:
In Stock
Product Type:
Modular base controller
Product Origin:
FR
Weight:
1720g
Shipping port:
Xiamen
Warranty:
12 months
TSX3721001 Specifications
Schneider Electric Main Specifications
| Parameter | Details |
|---|---|
| Range of Product | Modicon TSX Micro automation platform |
| Product or Component Type | Modular base controller |
| Primary Voltage | 100...240 V AC (90…264 V AC) |
| Input Current | 2 mA, 60 A |
| Immunity to Microbreaks | 20 ms |
| Output Current | 0.5 A |
Schneider Electric Complementary Specifications
| Parameter | Details |
|---|---|
| Number of Slots | 3 |
| Integrated Connection Type | 1 serial link (TER/AUX) Uni-Telway 19.2 kbit/s 1 Modbus Modbus RTU 19.2 kbit/s |
| Realtime Clock | With |
| Memory Description | Flash 15 Kwords data Internal RAM 20 Kwords data Internal RAM (with PCMCIA card) 128 Kwords program and data Internal RAM 128 Kwords data storage |
| Execution Time per Instruction | 0.13 µs Boolean without PCMCIA card 4.5 µs arithmetic REAL floating without PCMCIA card 0.19 µs Boolean with PCMCIA card 4.5 µs arithmetic REAL floating with PCMCIA card |
| Execution Time for 1 Kinstruction | 5.88 100 % Boolean without PCMCIA card 0.27 65 % Boolean and 35 % numerical without PCMCIA card 4 100 % Boolean with PCMCIA card 0.266 65 % Boolean and 35 % numerical with PCMCIA card |
| Application Structure | 16 event tasks 1 master task 1 fast task |
| System Overhead | 1.6 ms master task |
| Protection Type | Overload protection, Short-circuit |
| Total Useful Secondary Power | 16 W |
| Electromagnetic Compatibility | Electrostatic discharge IEC 1000-4-2 level 3 Electromagnetic field immunity test IEC 1000-4-3 level 3 Resistance to fast transient IEC 1000-4-4 level 3 Immunity to impulse waves IEC 1000-4-5 Damped oscillatory wave IEC 1000-4-12 Immunity to electromagnetic interference IEC 61131-2 |
Schneider Electric Environmental Specifications
| Parameter | Details |
|---|---|
| Ambient Air Temperature for Operation | 32…140 °F (0…60 °C) |
| Ambient Air Temperature for Storage | -13…158 °F (-25…70 °C) |
| Relative Humidity | 10…95 % without condensation for operation |
| Operating Altitude | 0...6561.68 ft (0...2000 m) |
Schneider Electric Physical Specifications
| Parameter | Details |
|---|---|
| Width | 13.4 in (341.4 mm) |
| Height | 5.9 in (151 mm) |
| Depth | 6.0 in (152 mm) |
| Net Weight | 3.79 lb(US) (1.72 kg) |
Schneider Electric Ordering and Shipping Details
| Parameter | Details |
|---|---|
| Category | US1PC1422556 |
| GTIN | 3389110580518 |
| Returnability | No |
| Country of Origin | FR |
| Packing Units | 1 PCE |
| Package 1 Dimensions | Height: 5.9 in (15.0 cm), Width: 6.7 in (17.0 cm), Length: 9.4 in (24.0 cm), Weight: 4.021 lb(US) (1.824 kg) |
