Technical Specifications:
Product Type:
CHARM Baseplate
Technical Specifications
| Parameter |
Specification |
| Model Number |
SE4601T07 |
| Baseplate Dimensions |
300 mm x 200 mm x 50 mm (L x W x H) |
| Weight |
1.5 kg |
| Input Voltage |
24 V DC |
| Current Rating |
10 A per terminal block |
| Temperature Range |
-20°C to +60°C |
| Material |
High-strength polycarbonate and aluminum |
| Mounting Type |
DIN rail mountable |
| Number of Terminal Blocks |
12 standard CHARM terminal blocks |
| Screw Terminal Size |
Accepts wire sizes from 0.5 mm² to 2.5 mm² |
