Technical Specifications:
Product Type:
Ethernet Backplane
Schneider Model: BMEXBP1200
Schneider Main
| Range of Product: |
Modicon X80 |
| Accessory / Separate Part Type: |
Rack |
Schneider Complementary
| Number of Slots: |
8 bus X + Ethernet, 4 bus X |
| Product Compatibility: |
- I/O module
- Specific application module
- BMXCPS power supply
- BMX processor
- BME processor
|
| Power Consumption in W: |
283 mW 3.3 V DC, 3.9 W 24 V DC |
| Electrical Connection: |
1 connector (XBE) expansion module |
| Fixing Mode: |
By 4 M6 screws plate, By 4 screws 0.17…0.25 in (4.32…6.35 mm) panel |
| Current Consumption: |
164 mA 24 V DC, 86 mA 3.3 V DC |
| MTBF Reliability: |
1166108 H |
| Net Weight: |
3.036 lb(US) (1.377 kg) |
Schneider Environment
| IP Degree of Protection: |
IP20 |
| Ambient Air Temperature for Operation: |
32…140 °F (0…60 °C) |
| Relative Humidity: |
5…95 % without condensation |
| Directives: |
2014/35/EU - low voltage directive, 2014/30/EU - electromagnetic compatibility |
Schneider Ordering and Shipping Details
| Category: |
US1PC3418160 |
| Discount Schedule: |
PC34 |
| GTIN: |
3595864173924 |
| Returnability: |
Yes |
| Country of Origin: |
FR |
Schneider Packing Units
| Unit Type of Package 1: |
PCE |
| Number of Units in Package 1: |
1 |
| Package 1 Dimensions: |
2.756 in x 6.299 in x 22.244 in (7.000 cm x 16.000 cm x 56.500 cm) |
| Package 1 Weight: |
3.042 lb(US) (1.380 kg) |
| Unit Type of Package 2: |
S04 |
| Number of Units in Package 2: |
8 |
| Package 2 Dimensions: |
11.811 in x 15.748 in x 23.622 in (30.000 cm x 40.000 cm x 60.000 cm) |
| Package 2 Weight: |
26.147 lb(US) (11.860 kg) |
