Technical Specifications:
Manufacturer:
Allen-Bradley
Product Type:
Communication Module
Technical Specifications
| Parameter |
Value |
| Ethernet Port |
1 x 10/100 Mbit/s RJ45 Ethernet port |
| Siemens PLC Compatibility |
Supports communication with Siemens S7-200, S7-1200, S7-300, and S7-400 PLCs as Ethernet servers. |
| Client Connections |
up to 20 simultaneous client connections |
| Data Transfer |
up to 5000 bytes of input/output data between ControlLogix PACs and Siemens PLCs |
| Ethernet Interface |
10/100 Mbit/s, full/half duplex, auto-negotiation. |
| Data Capacity |
Supports up to 5000 bytes of input/output data. |
| Power Requirements |
2.5 W @ 5 VDC, drawing power from the ControlLogix backplane. |
| Operating Temperature |
0°C to +60°C (32°F to 140°F), suitable for industrial environments. |
| Backplane Current Load |
800 mA @ 5 VDC |
| Isolation |
1500 VDC between Ethernet port and ControlLogix backplane for enhanced safety. |
| LED Indicators |
Status, activity, and error indicators for Ethernet and module diagnostics. |
| Dimensions |
145 mm x 35 mm x 138 mm (5.7 in x 1.4 in x 5.4 in), fitting standard ControlLogix slots |
