MPL-A4540C-HJ72AA Allen-Bradley AC Rotary Servo Motor

Technical Specifications

• Model: MPL-A4540C-HJ72AA
• Voltage: 200V AC
• Rated Speed: 1500 RPM
• Magnet Stack Length: 101.6 mm
• Diameter: 130 mm
• Encoder Type: Incremental encoder with 2000 lines/revolution
• Shaft Configuration: Shaft key for secure mounting
• Shaft Seal: No shaft seal, designed for clean environments
• Connector Type: Circular (SpeedTec) DIN connector
• Braking System: No brake included
• Operating Temperature Range: -20°C to 40°C (-4°F to 104°F)
• Weight: 19.70 lbs
• Protection Rating: IP65 (dust-tight and protected against water jets)

Performance Specifications

• Peak Torque: 1.5 Nm
• Rated Torque: 0.5 Nm
• Current Rating: 3.0 A
• Thermal Class: Class B (130°C)

Compliance and Certification

• Compliance: CE, UL, and RoHS compliant
