Technical Specifications:
Product No.:
KJ4006X1-BL1
Product Type:
Terminal Block
Technical Specifications
Power Specifications
| Parameter |
Specification |
| Field Power |
- 30 VDC at 100 mA (for nL and ic installations)
- 60 VDC at 1.0 A (for ec installations) |
Environmental Specifications
| Parameter |
Specification |
| Ambient Temperature |
-40°C to +70°C |
| Shock Resistance |
10g ½ Sinewave for 11 milliseconds |
| Vibration Resistance |
- 1mm Peak to Peak from 2 to 13.2 Hz
- 0.7g from 13.2 to 150 Hz |
| Airborne Contaminants |
ISA-S71.04 –1985 Airborne Contaminants Class G3 |
| Relative Humidity |
5 to 95% Non-Condensing |
Electrical Specifications
| Parameter |
Specification |
| Input Impedance |
10 kΩ (typical) |
| Signal Range |
-10 V to +10 V or 4 mA to 20 mA (user-configurable) |
| Isolation Voltage |
1500 VDC between channels and field power |
| MTBF (Mean Time Between Failures) |
> 100,000 hours (at 25°C) |
| Weight |
Approximately 200 grams |
| Dimensions |
100 mm x 50 mm x 25 mm (L x W x H) |
