Technical Specifications:
Product No.:
IS420ESWBH3A
Product Type:
Ethernet Switch
Technical Specifications
| Manufacturer |
GE Energy |
| Weight |
2 lbs |
| Quantity of Fiber Ports |
None |
| Operating Temperature |
-40 to 70°C |
| Input Voltage |
24/28 VDC |
| Functional Abbreviation |
ESWB |
| Dimensions |
H 18.8 cm x W 8.6 cm x D 5.6 cm |
| Copper Cables |
Cat 5e UTP Cable with RJ45 Connectors |
| Cooling Method |
Convection Cooled |
Ports
- Sixteen 10/100Base-TX RJ45 copper ports
- No fiber optic ports
Switching Capability
- Operates as a level one Ethernet switch
- Buffers multicast and broadcast packets
- Supports buffering of one packet per port
LED Indicators
- Power LED
-
Link LEDs:
- Solid Yellow: 10 MB link
- Solid Green: 100 MB link
- No light: No link
-
Activity LEDs:
- Flashing Green: Full duplex activity
- Flashing Yellow: Half duplex activity
DIN-Rail Clips
Requires clips 259B2451BVP1 and 259B2451BVP4 for secure mounting
