IC698ETM001 GE Fanuc Ethernet Interface Module

Product Overview: IC698ETM001 Ethernet Interface

• Manufacturer: GE Fanuc
• Features:
  • Provides high-performance Ethernet communications for the RX7i system.
  • Supports data exchange using Ethernet Global Data (EGD).
  • Offers TCP/IP communication services using SRTP.
  • Allows for full PLC programming and configuration services.
  • Equipped with comprehensive station management and diagnostic tools.
• Ports:
  • Two full-duplex 10BaseT/100BaseT/TX (RJ-45 Connector) ports with an internal network switch.
  • Auto-negotiated network speed, duplex mode, and crossover detection.
• Connectivity:
  • Compatible with IEEE 802.3 CSMA/CD 10Mbps and 100Mbps Ethernet LAN.
  • Up to three Ethernet Interface modules can be installed in an RX7i CPU rack.
• Installation:
  • Plugs into a single-width slot in an RX7i rack.
  • Configured using Proficy™ Machine Edition programming software.
• Upgrades:
  • Firmware is pre-loaded, maintained indefinitely, and upgradable in-system through the RX7i CPU serial port using WinLoader.
• Additional Features:
  • Supports Redundant IP addressing for use in systems with Hot Standby CPU Redundancy.
  • Features EGD Class 2 functionality including reliable data service and command transfers.
