Introduction

The IC695NIU001 is an Ethernet Network Interface Unit (NIU) designed for the PACSystems RX3i. This unit allows the use of PACSystems RX3i and Series 90-30 I/O modules over an Ethernet network, enabling remote I/O operations with automatic data exchange once configured.

Features

System Control and Status Monitoring

• Provides system control via any master device capable of exchanging Ethernet Global Data (EGD).
• Automatically provides the controller with status information, which can be monitored by the application program logic in the controller to issue commands to the Ethernet NIU.

Configuration and Compatibility

• Compatible with RX3i Universal Backplanes, RX3i power supplies, RX3i Ethernet modules, and optional Series 90-30 expansion backplanes.
• Supports various RX3i and Series 90-30 modules suitable for different applications.
• Requires Machine Edition Logic Developer software, version 5.51 or later.

Technical Specifications

Memory and Storage

• 20Kbytes of optional local logic, supporting all languages except C programming.
• 10 Mbytes of built-in flash memory for local user data storage.

Communication and Connectivity

• Embedded RS-232 and RS-485 serial ports.
• Supports Modbus RTU Slave, SNP, Serial I/O, and Modbus RTU Master protocols.
• Provides Ethernet communications via the backplane-based Ethernet Interface module (IC695ETM001).
• Supports data exchange using EGD and TCP/IP communication services using SRTP.

Power and Battery Requirements

• Power requirements: +3.3 VDC at 1.25 Amps nominal, +5 VDC at 1.0 Amps nominal.
• Includes a battery-backed calendar clock.
• Compatible with RX3i CPU Lithium Smart Battery (IC695ACC302), Series 90-30 Lithium Battery Pack (IC693ACC302), or IC698ACC701 Smart Coin Cell Battery Pack.

Environmental Specifications

• Operating temperature range: 0°C to 60°C (32°F to 140°F).
• For compliance with environmental standards such as FCC or European Union Directives, refer to the PACSystems RX3i Hardware and Installation Manual, GFK-2314.
