IC200MDL650 GE Fanuc VersaMax 4VDC Discrete Input Module

IC200MDL650 GE Fanuc VersaMax 4VDC Discrete Input Module

Technical Specifications:

Manufacturer:
GE
Product No.:
IC200MDL650
Condition:
In Stock
Product Type:
Discrete Input Module
Product Origin:
USA
Weight:
2000g
Shipping port:
Xiamen
Warranty:
12 months

IC200MDL650 Input Module, 24VDC Pos/Neg Logic 32 Points

Description

The IC200MDL650 Input Module provides 32 discrete input points, divided into four groups of 8 points each. The inputs can be configured for either positive logic, receiving current from input devices and returning it to the common, or negative logic, receiving current from the common and returning it to the input devices.

Module Specifications

  • Points: 32 (4 groups of 8)
  • Module ID: 80088008
  • Isolation:
    • User input to logic (optical) and to frame ground: 250VAC continuous; 1500VAC for 1 minute
    • Group to group: 250VAC continuous; 1500VAC for 1 minute
    • Point to point: None
  • LED Indicators:
    • One LED per point shows individual point ON/OFF status
    • OK LED indicates backplane power is present
  • Backplane Current Consumption: 5V output: 50mA maximum
  • External Power Supply: None
  • Thermal Derating: See diagram in the manual
  • Configuration Parameters: Input response times

Input Characteristics

  • Input Voltage: 0 to +30VDC, +24VDC nominal
  • On State Voltage: +15 to +30VDC
  • Off State Voltage: 0 to +5VDC
  • On State Current: 2.0 to 5.5mA
  • Off State Current: 0 to 0.5mA
  • On Response Time: 0.5ms maximum
  • Off Response Time: 0.5ms maximum
  • Configurable Filter Time: 0 ms, 1.0ms (default), or 7.0ms
  • Input Impedance: 10kOhms maximum

Dimensions (W x H x D): 110 mm (4.3 in) x 66.8 mm (2.63 in)x 50 mm (1.956 in), not including the height of the carrier or the mating connectors.
