Honeywell | MasterLogic-200 Series 2MLL-EFMF

Overview

The Honeywell 2MLL-EFMF Fast Ethernet Module is designed for seamless communication and robust network integration. With advanced network diagnostics and a user-friendly interface, this module supports a wide range of industrial applications, providing high-speed connectivity in the MasterLogic-200 series systems. Ideal for applications requiring reliable Ethernet communication, it integrates effortlessly into existing setups with protocols like TCP-IP and UDP-IP.

Technical Specifications:

• Brand: Honeywell
• Model: 2MLL-EFMF
• Ethernet Standard: IEEE802.3U
• Protocols Supported: TCP-IP, UDP-IP, MODBUS TCP Slave, MODBUS TCP Master, P2P
• Network Control Protocol: CSMA/CD (Carrier Sense Multiple Access with Collision Detection)
• Transmission Speed: 100 Mbps
• Transmission Method: Baseband
• Physical Layer: 100Base-TX, Twisted Pair
• Media: UTP/STP, CAT5, RJ45 connector
• Transmission Distance: 100 meters (using UTP/STP cables, Switch/Node)
• Current Consumption: 410 mA

Key Features:

• Maximum Nodes Supported: 64

• Service/Protocol Support:

  • HSL: Peer-to-Peer High-Speed Link for MasterLogic PLCs
  • MLDP: Interface with Experion System – MasterLogic Dedicated Protocol
  • Modbus TCP Slave: Yes
  • P2P Communication: Support for User-defined Protocols, Master communication
  • SoftMaster I/F: Compatible with SoftMaster-NM for easy configuration and diagnostics

• LED Indicators: RUN, I/F, HS, P2P, PADT, PC, ERR, TX, RX, 10/100

• Network Diagnostics:

  • Auto-scan
  • Ping Test
  • Frame Monitor
  • Link Monitor
