The MCAR-01 is a carrier that can be screwed onto any flat surface. It can accommodate one IOTA-R24 assembly. Below are its features and technical specifications:
Component Composition
A metal profile
A plastic cover plate
A ground rail with 16 ground connection screws
Two power rails with M5 holes (+24V and 0V)
Four mounting holes (6.35 mm diameter)
Technical Data
General Type number: FC-MCAR-01
Operating temperature: -40 to +70°C (-40 to +158°F)
Storage temperature: -40 to +85°C (-40 to +185°F)
Relative humidity: 10 to 95% (non-condensing)
Pollution: Pollution degree 2 or better
Approvals: CE; UL
Power Supply
Voltage: 24 V DC, range -15% to +30%
Supply current: none
Supply rail current: maximum 40 A
Connections
24V supply: 2 x M5
Ground: 16 x M5
Physical Data
Dimensions (H x W x D): 32 x 145.6 x 478 mm, or 2.52 x 5.73 x 18.8 in
