GE Fanuc IC200MDL329 VersaMax Discrete Isolated Output Module

Module Overview

The IC200MDL329 discrete output module provides 8 isolated outputs capable of handling 120VAC at 0.5 Amps. An external 120VAC power supply is required to switch power to the loads. The module receives 8 bits of discrete output data and features LED indicators for monitoring output states.

Module Specifications

• Module Characteristics
  • Points: 8 isolated outputs
  • Module ID: FFFF8840
  • Isolation:
    • User input to logic (optical) and to frame ground
    • Group to group
    • Point to point
    • 250VAC continuous; 1500VAC for 1 minute
  • LED indicators: One LED per point shows individual point on/off state; OK LED indicates backplane power is present
  • Backplane current consumption: 5V output: 70mA maximum
  • External power supply: 85 to 132VAC (47 to 63Hz), 120VAC nominal

Output Characteristics

• Output voltage: 85 to 132 VAC (47 to 63Hz), 120VAC nominal
• Output voltage drop: 2.0V maximum
• Load current: 10mA minimum per point; 0.5A maximum per point; 5.0A for one cycle (20ms) maximum inrush
• Output leakage current: Less than 2mA at 132VAC
• On response time: Less than ½ cycle, maximum
• Off response time: Less than ½ cycle, maximum
• Protection: Snubber and MOVs (each output)
• Diagnostics: None
