FC-TDOL-07120 Honeywell Digital Output Module

Introduction

The TDOL-07120 Field Termination Assembly Module serves as an interface for field loads requiring 120Vac or 120Vdc line-monitored digital outputs. It features 7 fused relay contact outputs with a maximum load of 240VA or 150W each.

Main Functions and Usage

• Connects to SDO-0824 output module and SDI-1624 input module via system interconnection cables.
• Controls 7 output relays through channels 1 to 7 of the SDO-0824, with LED indication of relay states.
• Line-monitoring circuits on each output channel, controlled by channel 8 of the SDO-0824 and wired to channels 1 to 15 of the SDI-1624.
• Drives outputs and processes line monitoring results with special application logic.

Technical Data

• Type Numbers: FS-TDOL-07120, FC-TDOL-07120
• Approvals: CE, UL, CSA, TUV
• Number of Channels: 7
• Max. Output Current: 2A (at 120V AC)
• Output Load: Resistive or inductive up to 240VA/150W
• Output Supply Voltage: 120V AC or 120V DC +/- 20%
• Fuse Rating: 2A
• Max Switched Power: 1250VA / 60 Watts
• Expected Life: 100,000 electrical switch operations, 30,000,000 mechanical switch operations
• Physical Dimensions: 240 x 109 x 71 mm (L x W x H)
