🚀 Genuine products, vast inventory, swift shipping!
Digital Input Module | 6ES7321-1BH02-0AA0 Siemens
Digital Input Module | 6ES7321-1BH02-0AA0 Siemens
Technical Specifications:
Manufacturer:
Siemens
Product No.:
6ES7321-1BH02-0AA0
Condition:
In Stock
Product Type:
Digital Input Module
Product Origin:
DE
Weight:
200g
Shipping port:
Xiamen
Warranty:
12 months
Siemens Product Information |
|
|---|---|
| Article Number (Market Facing Number): | 6ES7321-1BH02-0AA0 |
Siemens Supply Voltage |
|
|---|---|
| Load Voltage L+ (DC): | Rated value: 24 V |
| Permissible Range, Lower Limit (DC): | 20.4 V |
| Permissible Range, Upper Limit (DC): | 28.8 V |
Siemens Input Current |
|
|---|---|
| From Backplane Bus 5 V DC, Max.: | 10 mA |
Siemens Power Loss |
|
|---|---|
| Power Loss, Typ.: | 3.5 W |
Siemens Digital Inputs |
|
|---|---|
| Number of Digital Inputs: | 16 |
| Input Characteristic Curve in Accordance with IEC 61131, Type 1: | Yes |
| Number of Simultaneously Controllable Inputs: | Horizontal Installation: Up to 40 °C, Max.: 16 Up to 60 °C, Max.: 16 Vertical Installation: Up to 40 °C, Max.: 16 |
Siemens Input Voltage |
|
|---|---|
| Type of Input Voltage: | DC |
| Rated Value, DC: | 24 V |
| For Signal "0": | -30 to +5 V |
| For Signal "1": | 13 to 30 V |
Siemens Input Current |
|
|---|---|
| For Signal "1", Typ.: | 7 mA |
Siemens Input Delay (For Rated Value of Input Voltage) |
|
|---|---|
| For Standard Inputs: | Parameterizable: No |
| At "0" to "1", Min.: | 1.2 ms |
| At "0" to "1", Max.: | 4.8 ms |
Siemens Cable Length |
|
|---|---|
| Shielded, Max.: | 1000 m |
| Unshielded, Max.: | 600 m |
Siemens Encoder |
|
|---|---|
| Connectable Encoders: | 2-wire sensor: Yes |
| Permissible Quiescent Current (2-wire Sensor), Max.: | 1.5 mA |
Siemens Connection Method |
|
|---|---|
| Required Front Connector: | 20-pin |
Siemens Dimensions |
|
|---|---|
| Width: | 40 mm |
| Height: | 125 mm |
| Depth: | 120 mm |
Siemens Weights |
|
|---|---|
| Weight, Approx.: | 200 g |
