DC 32 Circuit Discrete Input And Output GE IC660TBD025

Overview

The GE Fanuc IC660TBD025, part of the Genius I/O series, is a 32-circuit discrete input and output block. Designed for multi-voltage DC applications, it combines compact dimensions, high efficiency, and robust isolation, making it a reliable component in industrial automation systems.

Features

• ⚡ Versatile Voltage Support: Rated for 5/12/24 Volts DC, with an operating range of 4.9 to 5.3 Volts DC, ensuring adaptability across multiple systems.
• 🔒 High Isolation: Offers 850 Volts block-to-block isolation for improved operational safety.
• ⏱ Quick Recovery: Power supply dropout recovery time is 4 milliseconds at 12 Volts and 20 milliseconds at 24 Volts.
• 🌡 Efficient Heat Management: Maximum heat dissipation of 18 Watts for reliable operation.
• 📏 Compact Size: Compact dimensions of 224 x 90 x 112 mm (8.8 x 3.5 x 4.4 inches), fitting easily into control panels.
• ⚖️ Lightweight: Weighs just 1.8 kg (4 pounds), ensuring ease of installation.

Technical Specifications

• Brand: GE Fanuc
• Model: IC660TBD025
• Series: Genius I/O
• Part Number: IC660TBD025
• Block Type: DC 32-circuit discrete input and output
• Rated Voltage: 5/12/24 Volts DC
• Operating Voltage: 4.9 to 5.3 Volts DC
• Ripple: 10% maximum for 12/24 Volts; 1% maximum for 5 Volts
• Power Supply Dropout Time: 4 milliseconds at 12 Volts / 20 milliseconds at 24 Volts
• Required DC Power: 150 milliamps typical / 300 milliamps maximum
• Heat Dissipation (Max): 18 Watts
• Block-to-Block Isolation: 850 Volts
• Dimensions (HxWxD): 224 x 90 x 112 mm (8.8 x 3.5 x 4.4 inches)
• Weight: 1.8 kg (4 pounds)
• Operating Temperature: 0 to 60°C (32 to 140°F)
• Storage Temperature: -40 to 100°C (-40 to 212°F)

Applications

• Automation Control: Ideal for managing discrete input and output signals in automated systems.
• DC System Monitoring: Ensures seamless operation in low-voltage DC environments.
• Industrial Safety Systems: Provides high-isolation circuitry for safety-critical processes.

FAQ

Q: What voltage ranges does the IC660TBD025 support?
A: This block supports 5/12/24 Volts DC, with a precise operating voltage range of 4.9 to 5.3 Volts DC.

Q: What is the power supply dropout recovery time?
A: It is 4 milliseconds at 12 Volts and 20 milliseconds at 24 Volts.

Q: How much power does it consume?
A: Typical power consumption is 150 milliamps, with a maximum of 300 milliamps.

Q: What is the maximum heat dissipation?
A: The IC660TBD025 dissipates up to 18 Watts of heat.

Q: How compact is the design?
A: The block measures 224 x 90 x 112 mm (8.8 x 3.5 x 4.4 inches) and weighs 1.8 kg (4 pounds).
