CC-IP0101 Honeywell Profibus Gateway Module

Honeywell CC-IP0101 Profibus DP Gateway Module

Description: The Honeywell CC-IP0101 Profibus DP Gateway Module is a device designed to facilitate seamless integration between Profibus DP networks and Honeywell’s Experion control systems. It acts as a bridge, enabling efficient communication and data exchange between these industrial automation protocols. The module supports both master and slave operations and can handle up to 127 Profibus DP devices.

Features:

1. Communication Bridge: Enables data exchange between Profibus DP devices and Honeywell Experion systems, supporting a variety of devices like sensors, actuators, and controllers.
2. Flexibility and Scalability: Supports baud rates from 9.6 kbps to 12 Mbps, enhancing system flexibility and scalability.
3. Data Filtering and Monitoring: Capable of filtering data based on device address or data type, and includes features for monitoring network traffic and diagnosing network issues.
4. Master and Slave Operations: Supports both roles, allowing versatile integration in various industrial setups.
5. Modular Design: Facilitates easy installation and maintenance within the Series 8 I/O Terminal Assembly (IOTA) platform.

Specifications:

• Communication Protocol: Profibus DP

• Data Transfer Rate: Up to 12 Mbps

• Power Supply: 24V DC

• Dimensions: 190 mm x 69 mm x 23 mm (7.5 in x 2.7 in x 0.9 in)

• Weight: 0.3 kg

• Power Consumption: 10 W

• Operating Temperature: -40 to 85 °C (-40 to 185 °F)

• Storage Temperature: -40 to 85 °C (-40 to 185 °F)

• Humidity: 5% to 95% non-condensing

• Vibration: 5 g peak at 20 to 500 Hz
