Allen-Bradley MPL-B4540F-SJ72AH Servo Motor

🔧 Features

• Model Variants:
  • MPL-B4540F-SJ72AH (Servo Motor)

• Voltage Rating: 460V AC for reliable industrial power systems.
• Frame Size: 130 mm frame for efficient integration into space-constrained environments.
• Rated Speed: 3000 RPM for high-speed applications.

🔩 Technical Specifications

• Power Rating: 4.5 kW (approx. 6 HP)
• Rated Torque:
  • Continuous: 12.0 Nm
  • Peak: 36.0 Nm
• Current Rating: 10.0 A (at 460V AC)
• Efficiency Class: Class IE3 (Premium Efficiency)
• Thermal Class: Class F (155°C)
• Service Factor: 1.0 (continuous duty)
• Vibration Level: ≤ 0.5 mm/s (ISO 10816)
• Noise Level: ≤ 70 dB(A) at rated speed
• Weight: 8.5 kg
• Feedback Type: Incremental encoder with high resolution for precise control.
• Operating Temperature Range: -20°C to 40°C.
• Protection Class: IP65 rated for dust and water resistance.
• Max Axial Load: 100 N
• Max Radial Load: 150 N
