ABB V18345-1010421001 TZIDC Electro-Pneumatic Positioner
ABB V18345-1010421001 TZIDC Electro-Pneumatic Positioner
Technical Specifications:
Manufacturer:
ABB
Product No.:
V18345-1010421001
Condition:
In Stock
Product Type:
Valve Positioner
Product Origin:
SE
Weight:
400g
Shipping port:
Xiamen
Warranty:
12 months
📊 Technical Specifications
Model: V18345-1010421001
Series: TZIDC Electro-Pneumatic Positioner
Brand: ABB
Parameter | Details |
---|---|
🔌 Input Signal | 4-20 mA (two-wire) input with a connector plug for LKS adapter. |
📡 Output Signal | 4-20 mA (analog), double-acting fail-safe. |
⚡ Power Supply Voltage | 5...11 V DC (for digital output). |
🔋 Control Voltage (Digital Input) | 0-5 V DC (logical "0"), 11-30 V DC (logical "1"). |
💨 Supply Pressure | 1.4...6 bar (20...90 psi). |
💨 Air Consumption | < 0.03 kg/h (0.015 scfm), independent of supply pressure. |
🔩 Connection Threads | Air pipe: 1/4-18 NPT; Cable: 1/2-14 NPT. |
🏠 Housing Material | Aluminum with electrostatic dipping varnish and epoxy resin, stove-hardened. |
🔒 Protection Rating | IP 65 (NEMA 4X). |
🔧 Mounting Options | Suitable for mounting to linear actuators (DIN/IEC 534 / NAMUR) and rotary actuators (VDI/VDE 3845). |
🎨 Surface Color | Case varnished black (RAL 9005, matte); Housing cover in Pantone 420. |
💥 Explosion Protection | No explosion protection in this model (0). |
🔌 Optional Modules | Available plug-in module for analog position feedback (4-20 mA). |
🔄 Digital Output | Control circuit to DIN 19234/NAMUR with supply voltage of 5-11 V DC. |
