ABB AI922 S900 I/O Analog Input Module

ABB AI922 S900 I/O Analog Input Module

Technical Specifications:

Manufacturer:
ABB
Product No.:
AI922
Condition:
In Stock
Product Type:
Analog Input Module
Product Origin:
SE
Weight:
600g
Shipping port:
Xiamen
Warranty:
12 months

Technical Specifications:

  • Input Channels: 8 differential analog inputs
  • Input Signal Types:
    • 0-20 mA, 4-20 mA (Current Input)
    • 0-10 V (Voltage Input)
    • RTD (Resistance Temperature Detectors)
  • Resolution: 16-bit A/D conversion for high signal fidelity
  • Input Impedance:
    • Voltage: ≥ 1 MΩ
    • Current: ≤ 250 Ω
  • Signal Range:
    • Voltage: 0 to 10 V
    • Current: 0 to 20 mA / 4 to 20 mA
    • RTD: PT100, PT1000, NI100, CU10
  • Accuracy:
    • ±0.05% of full scale for current and voltage inputs
    • ±0.1°C for RTD inputs
  • Isolation Voltage: 500 V AC between channels and system bus
  • HART Protocol: Supported on all channels
  • Update Time: < 10 ms per channel
  • Operating Temperature Range: -40°C to +70°C (-40°F to +158°F)
  • Power Supply Voltage: 24 V DC (redundant input supported)
  • Power Consumption: 2.5 W typical
  • Dimensions: 120 x 120 x 60 mm
  • Weight: 0.6 kg (1.32 lbs)
