6XV1875-5AH10 Siemens Flexible Connecting Cable

6XV1875-5AH10 Siemens Flexible Connecting Cable

Technical Specifications:

Manufacturer:
Siemens
Product No.:
6XV1875-5AH10
Condition:
In Stock
Product Type:
Flexible Connecting Cable
Product Origin:
DE
Weight:
141g
Shipping port:
Xiamen
Warranty:
12 months

Product Overview

Product Type Designation: Antenna Connection Cable N-Connect Plug/Plug

Product Description: Connecting cable for SIMATIC NET antennas, preassembled N-Connect male/male flexible connection cable. Length 1 m; flexible cable, suitable for IWLAN and mobile radio.

Electrical Data

Number of Electrical Connections: 2

Type of Electrical Connection: N-Connect/N-Connect male/male

Transmission Frequency: 0 ... 6000 MHz

Attenuation Factor per Length:

  • At 2.4 GHz: Typical 0.53 dB/m
  • At 5.2 GHz: Typical 0.83 dB/m
  • At 5.85 GHz: Typical 0.89 dB/m

Return Loss: Minimum 23 dB

Impedance: Rated Value 50 Ω

Capacity per Length at 1 kHz: 82 pF/m

Relative Speed: 82%

Mechanical Data

Design of the Shield: Braided shield made of tin-plated copper wires

Outer Diameter:

  • Inner Conductor: 1.4 mm
  • Dielectric: 3.8 mm
  • Cable Sheath: 6.3 mm

Symmetrical Tolerance of the Outer Diameter of Cable Sheath: 0.2 mm

Thickness of Cable Sheath: 0.76 mm

Material:

  • Inner Conductor: Copper (Cu)
  • Dielectric: Polyethylene foam
  • Cable Sheath: FRNC

Color of Cable Sheath: Pastel Turquoise

Bending Radius:

  • Single Bend: Minimum 32 mm
  • Multiple Bends: Minimum 45 mm

Tensile Load (Max): 80 N

Weight per Length: 75 kg/km

Ambient Conditions

Temperature Range:

  • During Operation: -40 to +80 °C
  • During Storage: -40 to +80 °C
  • During Transport: -40 to +80 °C
  • During Installation: -25 to +80 °C

Chemical Resistance: Conditional resistance to mineral oil

Radiological Resistance to UV Radiation: Resistant

Protection Class IP: IP68 when plugged in

Product Features

Halogen-Free: Yes

Silicon-Free: Yes
