Technical Specifications:
Product No.:
51202343-001
Product Type:
Status Indication Cable
Technical Specifications
| **Specification** |
**Details** |
| Voltage Rating |
30V DC |
| Current Rating |
1.0 Amps |
| Insulation Resistance |
>100 MΩ at 500V DC |
| Conductor Material |
Copper with tinned finish |
| Cable Length |
3.0 meters (9.8 feet) |
| Connector Type |
4-pin locking connector (M12 type) |
| Wire Gauge |
22 AWG |
| Outer Diameter |
5.0 mm (0.20 inches) |
| Sheath Material |
PVC, black |
| Bend Radius |
50 mm (2.0 inches) minimum |
| Operating Temperature Range |
-25°C to +80°C (-13°F to +176°F) |
| Storage Temperature Range |
-40°C to +85°C (-40°F to +185°F) |
| Humidity Range |
0% to 95% relative humidity, non-condensing |
| UV Resistance |
Yes, suitable for outdoor use |
| Flame Retardant |
Complies with IEC 60332-1-2 |
