Technical Specifications:
Product Type:
Fast Ethernet Module
Technical Specifications
| Product Number |
2MLL-EFMT |
| Product Type |
Fast Ethernet Module |
| Ethernet Speed |
10/100 Mbps (auto-negotiation) |
| Connector Type |
RJ-45 (Electric) |
| Supply Voltage |
24 VDC |
| Power Rating |
24V nominal |
| Current Consumption |
410 mA |
| Network Standard |
IEEE 802.3u (100BASE-TX) |
| Max Number of Nodes |
6 nodes |
| Protocols Supported |
-
TCP/IP: Reliable communication protocol for transmitting data.
-
UDP/IP: Fast, connectionless protocol for quick data transfer.
-
DHCP: Automatically assigns IP addresses to devices on the network.
|
| Data Transmission Method |
CSMA/CD |
| Environmental Operating Range |
Temperature: -20°C to +70°C
Humidity: 5% to 95% RH, non-condensing |
| Module Dimensions |
6.0 x 4.0 x 1.5 inches (15.24 x 10.16 x 3.81 cm) |
| Weight |
0.5 lbs (0.23 kg) |
| LED Indicators |
RUN, I/F, HS, P2P, PADT, PC, ERR, TX, RX, 10/100 |
