Technical Specifications:
Manufacturer:
Allen-Bradley
Product No.:
1606-XLS480E
Product Type:
Power Supply
Output Specifications
| Output Voltage |
DC 24V |
| Adjustment Range |
24-28V |
| Output Current |
- 20A continuous, 24V
- 30A for typ. 4s, 24V
|
| Output Power |
- 480W continuous, 24V
- 720W for typ. 4s, 24V
|
| Output Ripple |
< 100mVpp 20Hz to 20MHz |
Input Specifications
| Input Voltage |
AC 100-240V ±15% |
| Line Frequency |
50-60Hz ±6% |
| AC Input Current |
4.56 / 2.48A at 120 / 230Vac |
| Power Factor |
0.95 / 0.90 at 120 / 230Vac |
| AC Inrush Current |
typ. 9 / 7A peak at 120 / 230Vac |
| DC Input Voltage |
DC 110-300V - -20%/+25% |
| DC Input Current |
4.7 / 1.7A at 110 / 300Vdc |
Efficiency and Losses
| Efficiency |
92.4 / 93.9% at 120 / 230Vac |
| Losses |
39.6 / 31.4W at 120 / 230Vac |
Environmental Specifications
- Temperature range: -25°C to +70°C operational
- Derating: 12W/°C +60 to +70°C
- Hold-up time: typ. 32 / 51ms at 120 / 230Vac
Physical Specifications
| Dimensions (W x H x D) |
82x124x127mm |
