Technical Specifications:
Manufacturer:
Allen-Bradley
Product Type:
Power Supply
Input Specifications
| Input Voltage |
AC 100...120/200...240V (switchable), 47...63Hz
(AC 85...132/176...264V, DC 240...375V) |
| Input Current |
- <6A (switch in 115V position)
- <2.6A (switch in 230V position)
|
| DCin at Open Output |
8mA (preserves battery sources) |
| Inrush Current |
typ. <30A at AC 264V and cold start |
Transient Handling
Transient resistance acc. to VDE 0160 / W2 (750V/1.3ms), for all load conditions.
Performance
| Hold Up Time |
>25ms at AC 196V, 24V/10A |
| Efficiency |
typ. 90% (AC 230V, 24V/10A) |
| Losses |
typ. 26.7W (AC 230V, 24V/10A) |
| MTBF |
425,000h acc. to Siemensnorm SN 29500 (24V/10A, AC 230V, Tamb = +40°C) |
Lifecycle
The unit exclusively uses long-life electrolytics, specified for +105°C.
Startup Characteristics
Startup delay typ. 0.1s
Output Specifications
| Output Voltage |
DC 24...28V |
| Overvoltage Protection |
typ. 35V |
| Power Back Immunity |
34V |
Environmental Specifications
Humidity: Maximum 95%, non-condensing
Physical Specifications
| Dimensions (W x H x D) |
120mm x 124mm x 102mm (+ DIN rail) |
| Weight |
980g |
