16 Circuits, Inputs Only GE Fanuc IC660TBD110

Overview

The GE Fanuc IC660TBD110 is a Genius I/O series input-only block with 16 circuits. Designed to operate at 115 Volts AC, it ensures high reliability and robust performance for industrial environments, featuring strong isolation and efficient heat dissipation.

Features

• ⚡ Wide Voltage Range: Operates from 93 to 132 Volts AC, adaptable for various applications.
• 🔒 Enhanced Safety: Offers 1500 Volts of input-to-ground isolation for secure and reliable operations.
• 🌡 Temperature Resilience: Supports operation within 0 to 60°C and storage from -40 to 100°C.
• ⏱ Quick Recovery: 1-cycle power supply dropout time ensures minimal disruption.
• 📏 Compact Build: Space-saving dimensions of 224 x 88 x 100 mm (8.8 x 3.5 x 3.9 inches).
• ⚖️ Lightweight Design: Weighs 1.8 kg, simplifying installation and handling.

Technical Specifications

• Brand: GE Fanuc
• Model: IC660TBD110
• Series: Genius I/O
• Part Number: IC660TBD110
• Block Type: Input-only, 16 circuits
• Rated Voltage: 115 Volts AC
• Operating Voltage: 93 to 132 Volts AC
• Frequency: 47 to 63 Hertz
• Power Supply Dropout Time: 1 cycle
• Heat Dissipation (Max): 28 Watts
• Input-to-Ground Isolation: 1500 Volts
• Dimensions (HxWxD): 224 x 88 x 100 mm (8.8 x 3.5 x 3.9 inches)
• Weight: 1.8 kg (4 pounds)
• Operating Temperature: 0 to 60°C (32 to 140°F)
• Storage Temperature: -40 to 100°C (-40 to 212°F)

Applications

• Signal Monitoring: Suitable for industrial automation where discrete signal inputs are essential.
• High-Voltage Systems: Designed for environments requiring strong isolation and high-voltage reliability.
• Industrial Control Systems: Supports seamless integration with Genius I/O networks for advanced process control.

FAQ

Q: What is the input voltage range for the IC660TBD110?
A: It operates between 93 and 132 Volts AC.

Q: How much heat does the block dissipate?
A: The maximum heat dissipation is 28 Watts.

Q: What is the input-to-ground isolation voltage?
A: The block provides 1500 Volts of isolation.

Q: What are the dimensions of this block?
A: It measures 224 x 88 x 100 mm (8.8 x 3.5 x 3.9 inches).

Q: Is it suitable for extreme temperature conditions?
A: Yes, it operates from 0 to 60°C and can be stored from -40 to 100°C.
