151X1225EK01PC03 General Electric Charger Board

151X1225EK01PC03 General Electric Charger Board

Technical Specifications:

Manufacturer:
GE
Product No.:
151X1225EK01PC03
Condition:
In Stock
Product Type:
Charger Board
Product Origin:
USA
Weight:
800g
Shipping port:
Xiamen
Warranty:
12 months

Overview

The 151X1225EK01PC03 is a Charger Board from General Electric, commonly used in power conversion systems. This board is designed to manage power supply functions, including the charging of backup batteries, ensuring consistent operation of critical industrial equipment. It is a key component in ensuring the reliability and efficiency of power systems, particularly in environments where uninterrupted power is essential, such as industrial automation, energy plants, and infrastructure control systems.

Technical Specifications

Parameter Specification
P/N 151X1225EK01PC03
S/N IC3645B23C1DDG1
Input Voltage 110V AC or 220V AC ±10%
Output Voltage 24V DC ±5% (for charging)
Current Rating 10 A maximum
Battery Type Supported Lead-acid, Ni-Cd, or Li-ion rechargeable batteries
Charge Regulation Multi-stage charging (bulk, absorption, and float phases)
Efficiency Up to 90% energy efficiency in typical operating conditions
Overvoltage Protection 30V DC (shutdown)
Short Circuit Protection Yes, automatic recovery after short circuit removal
Operating Temperature Range -20°C to +60°C (-4°F to +140°F)
Storage Temperature Range -40°C to +85°C (-40°F to +185°F)
Humidity 0% to 95% relative humidity, non-condensing
Cooling Method Passive cooling with integrated heat sinks
Dimensions 150 mm (L) x 100 mm (W) x 40 mm (H)
Weight 0.8 kg (approx.)
Mounting Panel mount or DIN rail compatible
Certifications CE, UL, and RoHS compliant
Communication Protocol RS485 for remote monitoring and control
Indication LEDs For charging status, fault, and battery health
