Technical Specifications:
Product No.:
140CPU67160S
Product Type:
Unity Hot Standby Processor
Main
-
Range of Product: Modicon Quantum automation platform
-
Product or Component Type: Unity safety processor
-
Software Designation: Unity Pro XL safety
-
Backup Type: Lithium battery 990XCP98000
Complementary
| Clock Frequency |
266 MHz |
| Number of Slots |
10 |
| Number of Racks |
1 - local rack(s) |
| Number of Remote I/O Stations |
31 - 1 rack(s) per remote |
| Discrete I/O Number |
- Unlimited (13 slots max) - local - forbidden in Hot Standby application
- 31744 inputs, 31744 outputs - remote
|
| Analogue I/O Number |
- Unlimited (26 slots max) - local - forbidden in Hot Standby application
- 1984 inputs, 1984 outputs - remote
|
| Number of Optional Modules |
6 Ethernet 140NOE77111 |
| Maximum Number of Connections |
- 1 Modbus Plus - local
- 1 Modbus (RS232/485 Modbus/ASCII)
- 1 Ethernet TCP/IP - local
- 6 USB - local
|
| Integrated Connection Type |
- 1 Modbus local
- 1 Modbus Plus local
- 1 USB local
- 1 Ethernet TCP/IP Hot Standby 140NOE77111 local
|
| Checks |
- Process control
- Hot standby
|
|
Memory Description
|
- Expandable 7168 kB - program with PCMCIA card
- Expandable 8 MB - file storage with PCMCIA card
- Internal RAM 1024 kB - 512 kB for data
|
| Switch Function |
Key switch memory port on/off |
| Application Structure |
1 cyclic/periodic master task |
| Execution Time per Instruction |
- 0.09...0.12 µs on word
- 0.105...0.15 µs Boolean
- 0.96...1.02 µs on fixed-point arithmetic
|
| Execution Time for 1 Kinstruction |
- 5.03 ms 65 % Boolean and 35 % numerical
- 5.14 ms 100 % Boolean
|
| System Overhead |
1.5 ms for master task |
| Bus Current Requirement |
2500 mA |
| Maximum Supply Current |
- 90 A 60 °C lithium battery
- 60 µA lithium battery
|
| [Us] Rated Supply Voltage |
3 V DC lithium battery |
