The IOBUS-CPIO serves as a vital communication interface between the Controller chassis (CPCHAS-0001, CPCHAS-0002, or CPCHAS-0003) and one or more IO chassis (IOCHAS-0001S, IOCHAS-0001R, IOCHAS-0002S, IOCHAS-0002R, IOCHAS-0003S, or IOCHAS-0003R) through a vertical IO bus, facilitated by a 34-wire flat cable. This setup facilitates essential scan, test, and update actions between the QPP module and IO modules.
Technical Data:
General:
Type Number: FS-IOBUS-CPIO
Approvals: UL, CSA
Physical Connectors: 34-pole latch (female)
Weight: 0.31 kg
The IOBUS-CPIO ensures seamless and efficient communication between the Controller and IO chassis, enabling crucial functionalities for system operation and maintenance.
