Technical Specifications:
Product No.:
ATV310HU30N4E
Product Type:
Variable Speed Drive
Technical Specifications
Parameters
| Model |
ATV310HU30N4E |
| Power Rating |
3 kW (4 HP) |
| Input Voltage |
380 - 460 V AC, three-phase |
| Input Frequency |
50/60 Hz |
| Output Voltage |
0 - 460 V AC, three-phase |
| Output Frequency |
0.1 - 500 Hz |
| Motor Control |
V/F control |
| Overload Capacity |
150% for 60 seconds |
| Cooling Method |
Forced air cooling |
| Protection |
Overload, short-circuit, overvoltage |
| Communication |
Modbus RTU |
| Display |
7-segment display |
| Mounting |
Panel mounting |
| Dimensions |
143 mm (H) x 110 mm (W) x 172 mm (D) |
| Weight |
1.7 kg |
| Operating Temperature |
-10°C to 50°C |
| Storage Temperature |
-25°C to 70°C |
| Humidity |
5% to 95% non-condensing |
| Certifications |
CE, UL, cUL, RoHS |
Applications
-
Conveyors: Smooth control of speed and torque for efficient material handling.
-
Pumps: Energy-efficient speed control for various pump applications.
-
Fans: Regulation of air flow in ventilation and cooling systems.
-
Machine Control: Versatile use in different types of industrial machinery.
