A6410 Emerson EPRO Dual Channel Monitoring Module

Technical Specifications:

• Input Channels: 2 independent position input channels
• Position Measurement Range: ±100 mm (linear), 0-360° (rotary)
• Position Resolution: 0.1 μm
• Position Accuracy: ±1 μm
• Input Types: Supports incremental/absolute linear/rotary encoders, SSI, and Analog (0-10V, 4-20mA)
• Sampling Rate: 1 kHz per channel
• Digital Inputs: 4 (24VDC)
• Digital Outputs: 4 (24VDC, 0.5A)
• Communication Interface: Epro proprietary bus, Modbus RTU
• Power Supply: 24VDC (18-30VDC)
• Operating Temperature: -10°C to 60°C
• Dimensions: 45 x 120 x 120 mm (W x H x D)
• Mounting: DIN rail mounted
