6ES7155-6AU01-0CN0 | Siemens Schnittstellenmodul
6ES7155-6AU01-0CN0 | Siemens Schnittstellenmodul
Technical Specifications:
Manufacturer:
Siemens
Product No.:
6ES7155-6AU01-0CN0
Condition:
In Stock
Product Type:
Schnittstellenmodul
Product Origin:
DE
Weight:
120g
Shipping port:
Xiamen
Warranty:
12 months
Siemens 6ES7155-6AU01-0CN0 Specifications
Siemens General Information
| Parameter | Value |
|---|---|
| Product Type | SIMATIC ET 200SP Interface Module |
| Product Designation | IM 155-6PN/2 HF |
| Firmware Version | V4.2 |
| Number of Periphery Modules | Max. 64 Periphery modules + 16 ET 200AL modules |
| Redundancy | S2 redundancy |
| Hot Swapping | Multi-hot swapping |
| Isochronous Mode | Yes, 0.25 ms isochronous mode |
Siemens Electrical Specifications
| Parameter | Value |
|---|---|
| Rated Supply Voltage (DC) | 24 V |
| Permissible Voltage Range (DC) | 19.2 V to 28.8 V |
| Reverse Polarity Protection | Yes |
| Current Consumption, Max. | 700 mA |
| Inrush Current, Max. | 4.5 A |
| Power Loss, Typ. | 2.4 W |
Siemens Interfaces and Communication
| Parameter | Value |
|---|---|
| Number of PROFINET Interfaces | 1; 2 ports with integrated switch |
| BusAdapter Compatibility | BA 2x RJ45, BA 2x FC, BA 2x SCRJ, BA SCRJ / RJ45, BA SCRJ / FC, BA 2x LC, BA LC / RJ45, BA LC / FC |
| Supported Protocols | PROFINET IO, Open IE communication, PROFIenergy, TCP/IP, SNMP |
| Media Redundancy | Yes, MRP client |
| Isochronous Mode | Yes, with bus cycle time of min. 250 µs |
Siemens Physical Dimensions
| Parameter | Value |
|---|---|
| Width | 50 mm |
| Height | 117 mm |
| Depth | 74 mm |
| Weight (approx.) | 120 g (without BusAdapter) |
