3500/40M 140734-01 Bently Nevada Proximitor Monitor

Description

The Bently Nevada 3500/40M 140734-01 Proximitor Monitor is a four-channel device designed to interface with Bently Nevada proximity transducers. It conditions the input signals to provide various vibration and position measurements, which are then compared with user-programmable alarms. This monitor is an essential component in machinery condition monitoring systems, particularly for rotating equipment in industrial environments.

Features

• Channel Capacity: Supports up to four proximity transducer signals.
• User-Programmable Alarms: Allows for customized monitoring settings.
• LED Indicators: Features front panel LEDs for status indicators, including OK, TX/RX, and Bypass.
• Power Consumption: Consumes 7 watts of power.
• Measurement Functions: Capable of radial vibration, thrust position, differential expansion, eccentricity, and REBAM (Rolling Element Bearing Absolute Motion).

Specifications

• Input Impedance: Standard I/O input impedance is 10 kΩ.
• Accuracy:
  • Direct/Gap/1X/2X: ±0.33% of full scale.
  • Smax: ±5% maximum.
• Power Requirements: Uses 7 watts.

Dimension:

• 241.3 mm x 24.4 mm x241.8 mm(9.50 in x 0.96 in x 9.52 in)

Weight:

• 0.91 kg (2.0 lb)
