330130-040-12-CN Bently Nevada 3300 XL Extension Cable

Technical Specifications

• Manufacturer: Bently Nevada
• Product No.: 330130-040-12-CN
• Product Type: 3300 XL Extension Cable
• Cable Length: 4.0 metres (13.1 feet)
• Connector Protector and Cable Option: 12 = FluidLoc® cable with connector protectors
• Cable Type: Shielded, twisted pair
• Insulation Material: Polyurethane
• Operating Temperature: -40°C to +85°C
• Maximum Voltage: 30 V
• Current Rating: 3 A
• Outer Diameter: 6.0 mm
• Weight: 0.3 kg/m
• Minimum Bend Radius: 30 mm
• Resistance: Oil, water, and abrasion-resistant
• Certification: RoHS compliant, CE marked
• Impedance: 100 Ohms
• Capacitance: 60 pF/m
• Inductance: 0.6 µH/m
• Insulation Resistance: >10 GΩ/km
• Propagation Delay: 5.3 ns/m
• Attenuation: 0.5 dB/m at 1 MHz
• Flex Life: >1 million cycles (at minimum bend radius)
• Flame Rating: UL 1581 VW-1
