Technical Specifications:
Manufacturer:
Allen-Bradley
Product Type:
CompactLogix 32 Pt 24VDC D/O Module
Output Specifications for 1769-OB32
| Specification |
Detail |
| Operating Voltage |
24V dc |
| Voltage Category |
20.4V dc to 26.4V dc (source) |
| Number of Outputs |
32 |
| Current Draw Max. |
300 mA at 5V dc (1.5W) |
| Heat Dissipation |
4.5 W |
| Signal Delay (max) - resistive load |
Turn-on: 0.1 ms / Turn-off: 0.1 ms |
| Off-State Leakage (max) |
1.0 mA at 26.4V dc |
| On-State Current (min) |
10.0 mA at 20.4V dc |
| On-State Voltage Drop (max) |
1.0V dc at 0.1 A |
| Continuous Current Per Output |
1.0 A at 30°C (86°F) |
| Continuous Current Per Common Max. |
8.0 A at 30°C (86°F) |
| Surge Current |
20.0 A (Repeatable every 2 seconds for a duration of 10 ms) |
| Modules Distance Factor |
Module may not be more than 6 modules away from the power supply |
| Isolated Groups |
Group 1: outputs 0 to 15, Group 2: outputs 16 to 31 |
| Vendor ID |
Code 7 |
| Product Type Code |
1 |
| Product Code |
73 |
