DFC 01 ABB - FieldController Module

DFC 01 Technical Specifications

Model: DFC 01
Manufacturer: ABB
Country of Origin: Germany (DE)

Technical Parameters:

• Processor:

  • Type: 32-bit ARM Cortex-M4
  • Speed: 168 MHz

• Memory:

  • RAM: 256 KB
  • Flash Memory: 1 MB

• Power Supply:

  • Input Voltage: 24 V DC
  • Power Consumption: 5 W

• I/O Configuration:

  • Digital Inputs: 16 channels (24 V DC)
  • Digital Outputs: 16 channels (24 V DC, 0.5 A per channel)
  • Analog Inputs: 8 channels (0-10 V, 4-20 mA)
  • Analog Outputs: 4 channels (0-10 V, 4-20 mA)

• Communication Ports:

  • Ethernet: 1 port (10/100 Mbps)
  • RS-232: 1 port
  • RS-485: 1 port
  • USB: 1 port (USB 2.0)

• Protocol Support:

  • Modbus TCP/IP
  • Modbus RTU
  • Profinet
  • Ethernet/IP

• Expansion Slots:

  • Up to 3 expansion modules

• Environmental Conditions:

  • Operating Temperature: -20°C to +60°C
  • Storage Temperature: -40°C to +85°C
  • Humidity: 5% to 95% non-condensing

• Dimensions and Weight:

  • Dimensions: 150 mm x 90 mm x 60 mm
  • Weight: 0.8 kg

• Certifications:

  • CE
  • UL
  • RoHS
