51304487-150 | Honeywell MC-PDOX02 Digital Output Processor

Name: 51304487-150 | Honeywell MC-PDOX02 Digital Output Processor
Brand: Honeywell
SKU: 51304487-150
Price: 60.0 USD
Availability: InStock

Technical Specifications:

Manufacturer:

Honeywell

Product No.:

51304487-150

Condition:

In Stock

Product Type:

Digital Output Processor

Product Origin:

USA

Weight:

500g

Shipping port:

Xiamen

Warranty:

12 months

Саны

Description

The Honeywell MC-PDOX02 is a Digital Output Processor designed to handle 16 digital outputs. This model features a conformal coating, providing enhanced protection against environmental factors such as humidity and dust. It is suitable for various industrial applications requiring robust and reliable digital output processing.

Technical Specifications

Specification	MC-PDOX02
Number of Output Channels	16
Output Type	Power transistor switch (3-30 Vdc / 31-200 Vdc FTA) or Triac switch (120/240 Vac FTA)
Load Voltage Range	3-30 Vdc (MU-TDOD13, 53), 5-30 Vdc (MU-TDOD14, 54), 120/240 Vac (120/240 Vac FTA), 31-200 Vdc (MU-TDOD23, 63)
Maximum Continuous Load Current	1.25 Adc per output (3-30 Vdc FTA / 120/240 Vac FTA), 0.5 Adc per output (31-200 Vdc FTA)
Load Fuse Rating	2.5 A, 125 V slow blow (3-30 Vdc FTA / 120/240 Vac FTA), 1 A, 125 V slow blow (31-200 Vdc FTA)
Fuse Type	BUSS GDC-2.5 A (3-30 Vdc FTA / 120/240 Vac FTA), BUSS GDC-1 A (31-200 Vdc FTA)
Load Power Factor	Must be 0.5 or greater (120/240 Vac FTA), N/A (3-30 Vdc FTA / 31-200 Vdc FTA)
Minimum Load Current	10 mAdc (3-30 Vdc FTA / 31-200 Vdc FTA), 50 mA (rms) (120/240 Vac FTA)
Isolation	1500 V (rms) (field terminals to system power supply common)
On-State Voltage Drop (at max. load current)	1.6 V max. (MU-TDOD13, 53 / 120/240 Vac FTA), 3.0 V max. (MU-TDOD14, 54 / 31-200 Vdc FTA)
Off-State Leakage Maximum	10 µAdc max. (MU-TDOD13, 53), 100 µAdc max. (MU-TDOD14, 54)
Coating	Yes (conformal coating for enhanced protection)
Dimensions (H x W x D)	130 x 40 x 100 mm
Weight	0.5 kg
Ordering Number	51304487-150

Features

Conformal Coating: Provides additional protection against environmental conditions.
High Isolation Voltage: Ensures safety and reliability with 1500 V AC isolation.
Fast Response Time: Less than 1 ms, suitable for high-speed applications.
Robust Design: Suitable for a wide range of industrial environments.

Notes

Environmental Protection: The conformal coating helps protect the module from moisture, dust, and other environmental factors, extending its lifespan and reliability.
Compliance: The MC-PDOX02 complies with relevant EMC standards and is designed for demanding industrial applications.
