The 161204-01 Bently Nevada 3500/91 EGD Gateway Module is designed to provide a reliable interface between the 3500 monitoring system and Ethernet Global Data (EGD) networks. This module facilitates the integration of machinery protection data into broader plant control and monitoring systems, enhancing overall operational efficiency and safety.
Technical Specifications
Protocol: Ethernet Global Data (EGD)
Communication Speed: 10/100 Mbps
Supported Networks: Ethernet TCP/IP
Input Voltage Range: 18 to 36 VDC
Power Consumption: 7.5 Watts
Operating Temperature: 0°C to +60°C
Relative Humidity: 0 to 95% non-condensing
Data Transfer Rate: Up to 100 Mbps
LED Indicators: Power, Link, Activity
Physical Specifications
Dimensions: 241.3 mm x 24.4 mm x 241.8mm (9.50 in x 0.96 in x 9.52in)
