Technical Specifications:
Product No.:
6ES7653-2CG00-0XB0
Product Type:
Scheda di espansione
Siemens 6ES7653-2CG00-0XB0 Specifications
Siemens General Information
| Parameter |
Value |
| Product Type |
SIMATIC PCS 7 System Expansion Card PO 2k+ |
| Hardware Functional Status |
FS03 |
| Firmware Version |
V2.0 |
| Operating Temperature (Max.) |
70°C |
Siemens Memory
| Parameter |
Value |
| PCS 7 Process Objects |
Approx. 2,600 POs for CPU 410-5H |
| Integrated Work Memory |
Use of max. 32 MB work memory in the CPU 410-5H |
| Expandable |
No |
Siemens Address Area
| Parameter |
Value |
| Inputs |
Use of 16 KB in the CPU 410-5H |
| Outputs |
Use of 16 KB in the CPU 410-5H |
Siemens Standards, Approvals, and Certificates
| Approval |
Status |
| CE Mark |
Yes |
| CSA Approval |
Yes |
| UL Approval |
Yes |
| cULus |
Yes |
| FM Approval |
Yes |
| RCM (formerly C-TICK) |
Yes |
| KC Approval |
Yes |
| EAC (formerly Gost-R) |
Yes |
| ATEX |
ATEX II 3G Ex nA IIC T4 Gc |
Siemens Physical Dimensions
| Parameter |
Value |
| Width |
8 mm |
| Height |
16 mm |
| Depth |
25 mm |
| Weight (Approx.) |
20 g |
