Manufacturer Details

Bently Nevada manufactures the 3300 XL 11 mm Proximitor Sensor, known for its precision and reliability in various industrial monitoring applications.

Product Information

Part Number: 330780-51-00
Product Type: 3300 XL 11 mm Proximitor Sensor
Country of Origin: Made in U.S.A

Materials

Constructed with A308 aluminum, this sensor is designed for durability in demanding industrial environments. The connectors are made from gold-plated brass or gold-plated beryllium copper, providing superior conductivity and resistance to corrosion.

System Length and Options

The system length options include 5 or 9 meters (including the extension cable) or 1 meter (probe only). The specific suffix options are:

• 330780: Refers to the 3300 XL 11 mm Proximitor Sensor.
• -51: Specifies a total system length of 5.0 meters (16.4 feet) with a DIN mount.
• -00: Indicates that no agency approval is required.

Temperature and Humidity Specifications

Operating Temperature: -52°C to +100°C (-62°F to +212°F)
Storage Temperature: -52°C to +105°C (-62°F to +221°F)
Relative Humidity: The sensor can handle 100% condensing humidity when connectors are protected. It has been tested to IEC 68-2-3 damp heat standards.

Dimensions and Weight

Dimensions: 81.3 mm x 61 mm x 63.5 mm (3.2" x 2.4" x 2.5")
Weight: 246 grams (8.67 ounces)

This detailed overview underscores the robust construction, versatile options, and reliable performance characteristics of the 3300 XL 11 mm Proximitor Sensor, making it suitable for a wide array of industrial applications.
