IC200MDL636 GE Fanuc 48 VDC Positive Negative Logic Input Module
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Module Overview
The IC200MDL636 is a discrete input module providing four groups of 8 discrete inputs each. These inputs can be configured as either positive or negative logic, accommodating various input devices.
Power Supply
Power for module operation is supplied through the backplane. Intelligent processing is handled by the CPU or NIU.
LED Indicators
Individual green LEDs indicate the on/off state of each input point. The OK LED illuminates when backplane power is present.
Configuration Parameters
The module offers a basic input on/off response time of 0.5ms. Software configuration allows for selectable input filter times of 0ms, 1.0ms (default), or 7.0ms, resulting in total response times of 0.5ms, 1.5ms, and 7.5ms, respectively.
Module Specifications
-
Module Characteristics
- Points: 32 (4 groups of 8)
- Module ID: 80088008
- Isolation:
- User input to logic and to frame ground: 250VAC continuous; 1500VAC for 1 minute
- Group to group: 250VAC continuous; 1500VAC for 1 minute
- Point to point: None
- LED indicators: One LED per point shows individual point ON/OFF status; OK LED indicates backplane power presence
- Backplane current consumption: 5V output: 140mA maximum
- External power supply: None
- Thermal derating: Refer to diagram
-
Input Characteristics
- Input voltage: 0 to 60VDC, 48VDC nominal
- User input current: 1.7mA typ. @ 48VDC, 2.1mA typ. @ 60VDC
- Input impedance: 28K Ohm typ.
- On state voltage: 34VDC to 60VDC
- Off state voltage: 0 VDC to 10VDC
- On state current: 1.0mA minimum
- Off state current: 0 to 0.4mA maximum
- On response time: 0.5ms maximum
- Off response time: Configurable filter time: 0 ms, 1.0ms (default), or 7.0ms
