UR 8NH GE Multilin UR-8NH CT/VT Module

Technical Specifications

• Current Input Range:

  • Rated Primary Current: 1A to 5000A

  • Rated Secondary Current: 1A or 5A (configurable)
• Voltage Input Range:

  • Rated Primary Voltage: 100V to 500kV

  • Rated Secondary Voltage: 100V (configurable)
• Frequency Range:

  • 50/60 Hz ± 5%
• Measurement Accuracy:

  • Current: ±0.5% of reading ±0.5% full scale

  • Voltage: ±0.5% of reading ±0.5% full scale
• Sampling Rate:

  • 64 samples per cycle
• Operating Temperature:

  • -40°C to +70°C
• Power Supply:

  • Voltage: 24-250V DC or AC

  • Consumption: < 10W
• Weight:

  • 1.15 kg
