SP1403 Emerson SP Unidrive Servo Drive

Technical Specifications

• Manufacturer: Emerson
• Product No.: SP1403
• Product Type: Unidrive SP Panel Mounted
• Modules: SP1403
• Frame Size: 1

Normal Duty

• Max Continuous Current (A): 5
• Typical Motor Output Power:
  • kW: 2.2
  • HP: 3

Heavy Duty

• Max Continuous Current (A): 4.2
• Typical Motor Output Power:
  • kW: 1.5
  • HP: 3

Input Power

• Type: 3-phase
• Voltage: 380-480 VAC
• Frequency: 50/60 Hz

Output Power

• Range: 0.4 kW to 15 kW

Output Frequency

• Range: 0 to 400 Hz

Speed Control

• Range: 1:1000
• Regulation: ±0.01%

Torque Control Accuracy

• Accuracy: ±5%

Environmental Specifications

• Ambient Temperature: 0°C to 40°C
• Ingress Protection: IP20
