Technical Specifications:
Product No.:
KJ3222X1-BK1
Product Type:
AI 8-CH 4-20mA HART Card
Brand: Emerson DeltaV
Model: KJ3222X1-BK1
Product Type: AI 8-CH 4-20mA HART Card
Hazardous Area Approvals
-
ATEX: II 3G Ex nA [nL] IIC Gc, II 3G Ex ec [ic] IIC Gc
-
IECEx: FMG 19.0019U
-
FM: FM19ATEX0173U, FM21UKEX0017U
-
Class I: Div. 2, Groups A, B, C, D
-
Class I, Zone 2: AEx/Ex ec [ic] IIC Gc
Power Specifications
| Specification |
Value |
| Local Bus Power |
12 VDC at 150 mA |
| Bussed Field Power |
24 VDC at 300 mA |
| Field Circuit |
24 VDC at 30 mA/Ch |
Environmental Specifications
| Specification |
Value |
| Ambient Temperature |
-40 °C to +70 °C |
| Shock |
10 g half-sine wave for 11 ms |
| Vibration |
1 mm peak to peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz |
| Airborne Contaminants |
ISA-S71.04 –1985, Class G3 |
| Relative Humidity |
5 to 95% Non-Condensing |
| Terminal Block Key Position |
A1 |
