EPRO MMS 6410 Dual Channel Measuring Amplifier

MMS 6410 Dual Channel Measuring Amplifier - Technical Overview

Brand: Emerson EPRO

Model: MMS 6410，MMS6410
Product Type: Dual Channel Measuring Amplifier for Inductive Displacement Sensors

Applications:

The MMS 6410 is engineered for monitoring and measuring shaft displacements utilizing inductive transducers in various configurations.

Technical Specifications:

• Sensor Inputs: Two independent inputs for half- or full-bridge configurations and differential transformers.
• Signal Frequency Range: 0 to 100 Hz at -3dB.
• Measuring Ranges: Customizable based on transducer measuring range.
• Sensor Supply: Buffered outputs for each input, balanced to ground to minimize disturbances.
• Interfaces: RS 232 and RS 485 for configuration and integration into host systems.
• Limit Supervision: Two adjustable alarm limits per channel, with configurable delay and hysteresis settings.

Environmental Conditions:

• Operating Temperature: 0 to +65°C
• Storage Temperature: -30 to +85°C
• Humidity Tolerance: 5 to 95%, non-condensing
• Vibration and Shock Resistance: Compliant with IEC standards for industrial environments.

Dimensions and Power:

• Dimensions: 100 x 160 mm (PCB/EURO card format)
• Supply Voltage: 18V to 31.2V DC
• Power Consumption: Max 8 W

Additional Information:

• Configuration: Via RS 232 or RS 485 interface, allowing for real-time adjustments and monitoring.
• Expansion: Supports up to 62 channels per RS 485 bus, with options for additional buses as needed.
