Technical Specifications:
Product No.:
KJ3241X1-BA1
Product Type:
Serial Interface Card
VE4006P2 KJ3241X1-BA1 12P2506X062 Serial Interface Card
Technical Parameters
| Parameter |
Specification |
| Local Bus Power Voltage |
12 VDC |
| Local Bus Power Current |
100 mA |
| Bussed Field Power Voltage |
24 VDC |
| Bussed Field Power Current |
75 mA |
| Field Circuit Voltage |
24 VDC per channel |
| Field Circuit Current |
5 mA per channel |
| Ambient Temperature Range |
-40°C to +70°C |
| Shock Rating |
10g ½ Sinewave for 11msec |
| Vibration Range |
1mm Peak to Peak (2 to 13.2Hz); 0.7g (13.2 to 150Hz) |
| Airborne Contaminants Class |
ISA-S71.04 –1985 Class G3 |
| Relative Humidity Range |
5% to 95% Non-Condensing |
| IP Rating |
IP 20 |
