Description: The Bently Nevada 3300 XL 11 mm Proximitor Sensor is engineered for precise measurement and monitoring in industrial environments. It measures the distance between a probe tip and a conductive target, offering accurate and reliable data essential for effective machinery maintenance and monitoring.
Features:
High Precision Measurement: Delivers accurate proximity measurements for critical industrial applications.
Durable Construction: Constructed from A308 aluminum, ensuring robustness and longevity.
Superior Connectors: Equipped with gold-plated brass or gold-plated beryllium copper connectors, providing excellent conductivity and corrosion resistance.
Flexible System Length: Available in system lengths of 5 or 9 meters, or 1 meter for the probe only, offering versatile installation options.
Specifications:
Material: A308 aluminum
Connector Material: Gold-plated brass or gold-plated beryllium copper
System Length: 5 or 9 meters (including extension cable) or 1 meter (probe only)
Dimensions (L x W x H): 81.3 mm x 61 mm x 63.5 mm (3.2" x 2.4" x 2.5")
Proximitor Sensor Temperature Range:
Operating Temperature: -52°C to +100°C (-62°F to +212°F)
Storage Temperature: -52°C to +105°C (-62°F to +221°F)
Relative Humidity: 100% condensing, non-submersible when connectors are protected, tested to IEC 68-2-3 damp heat
Weight:
Approximate Weight: 246 g (8.67 oz)
Suffix Options:
330780: 3300 XL 11 mm Proximitor Sensor
-50: Total length and mounting option are 5.0 meters (16.4 feet) system length, panel mount
