Technical Specifications:
Product Type:
Fail-safe Digital Output Module
Honeywell Product Information
| Manufacturer |
Honeywell |
| Product No. |
10201/2/1 |
| Product Type |
Fail-safe Digital Output Module |
Honeywell General Specifications
| Type Number |
10201/2/1 |
| Model Type |
11501 |
| Approvals |
CE, UL |
| Software Versions |
= 3.00 |
| Space Requirements |
4 TE, 3 HE (= 4 HP, 3U) |
Honeywell Power Requirements
| 5 Vdc |
25 mA |
| 24 Vdc Internal |
25 mA |
| 24 Vdc External |
70 mA (without output load) |
Honeywell Output Specifications
| Number of Output Channels |
8 |
| Output Specification |
24 Vdc solid-state source, short-circuit proof |
| Maximum Current |
550 mA* |
| Maximum Lamp Load |
120 mA (2.9 W)* |
| Maximum Load Capacitance |
1 µF |
| Voltage Drop |
< 2.0 Vdc at 500 mA* |
| Off Current |
< 0.1 mA |
| WDG Input Current |
8 mA |
Honeywell Key Coding
| Module Code |
Holes A9, C9 |
| Rack Code |
Large pins A9, C9 |
Honeywell Dimensions
| Dimensions |
1" x 8" x 6" (3 cm x 20 cm x 15 cm) |
| Weight |
0.7 kg |
