Yokogawa SDV531-L63 Digital output module
Manufacturer:
Yokogawa
Product No.:
SDV531-L63
Condition:
In Stock
Product Type:
Digital output module
Product Origin:
JP
Weight:
340g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Model: YokogawaSDV531-L63 Digital Output Module (8-channel, 24 V DC, module isolation)
Suffix Codes:
- -L: Long distance type
- 6: With signal cable interface adapter and no explosion protection
- 3: With ISA Standard G3 and temperature (-20 to 70 °C)
Item Specifications:
| Item | Specifications |
|---|---|
| Number of outputs | 8-channel, module isolation |
| Output voltage | 24 V DC |
| Output voltage drop | 1 V maximum |
| External power supply rating | 24 V DC, 5 A minimum |
| External power supply | 24 V DC +20 %/–10 % |
| Current capacity | 5 A |
| Maximum leak current at output off status | 1.6 mA |
| Output format | Current source |
| Maximum load current | 0.6 A/output line (4.8 A total output lines) |
| Minimum load current | 35 mA |
| Load resistance range | 40 to 685 Ω |
| Output response time | 30 ms maximum |
| Withstand voltage | 2 kV AC between output signal lines and system (1 minute) |
| Current consumption | 280 mA maximum (5 V DC), 140 mA maximum (24 V DC) |
| Weight | Approx. 0.28 kg (Pressure clamp terminal block or MIL cable), Approx. 0.34 kg (With dedicated signal cable interface adapter) |
External Connection:
- Pressure clamp terminal
- MIL cable
- Dedicated signal cable (AKB331, AKB651)
Notes:
- 1: The module supports a mechanism to prevent wrong type I/O module insertion with the signal cable.
- 2: When used in dual-redundant configuration, order an additional module with the same specification but without option codes.
- 3: Option codes for prevention pin of false insertion are available when selecting SDV531-6 or -F.
